Wiesser MV500M
CNC Vertical Machining Center
Standard Machine Features
60 m/min Speed Rapid Movements;
20 m/min. Perfect Cutting Progress
1.5 G acceleration
Direct Motor High Torque Spindle
20 Station Arm Type High Speed ATC
Big Plus BBT-40 Royal Brand Spindle
JAPANESE design strong and wide body structure
Long-term rigidity with rasping at 17 different points in the Cast Body
Perfect rigidity and precision with Roller (Bobbin) Linear Guides
Super Precision C1 class Ball Screws in all axes
Extra Supported Durable Outer Case
Cooling water system and Boron oil gun
Pressurized bottom chip washing system (Wash Down)
Japanese Mitsubishi Brand Axis Drivers and Axis Motors (Direct Motor)
Rigit Tapping
Spiral type chip conveyor, Fully closed case
Warning lamp showing machine operating status
Interior Lighting lamp, Machine mounting foot set
Transformer, CE and Toolbox, Programming and Maintenance Book Set
FANUC Oİ-MF AICC2 + R660 (FINE MOULD MACHINING PACK)
Fanuc high speed high quality machining package + Data server
Smooth tolerance control
Jerk Control
Machining Quality Control Adjustment Option
Nono Smoothing
