Capacity Information
Table dimensions : 2.000 x 1.000 (mm)
T Channel dimensions : 22 x 7 x 150 (mm)
Table loading capacity : 4.000 (kg)
X Axis Travel : 1.800 (mm)
Y Axis Travel : 1.300 (mm)
Z Axis Travel : 770 (mm)
Distance between spindle face and table : 150 ~ 920 (mm)
Distance between two columns : 1.300 (mm)
Spindle motor power : 18,5 (kW)
Spindle taper : BT-50
Max. spindle speed : 6.000 (rpm)
Spindle - Motor transmission type : Belt Type / Option: Italian BF Gearbox
Automatic magazine type : Arm Type
Number of magazine stations : 24 (pcs)
Max. tool diameter Standard / Side pots empty: 110 / 220 (mm)
Max. tool length : 300 (mm)
Ball screw diameter X*Y*Z : 63*50*50 (mm)
Ball screw pitch X*Y*Z : 12*10*10 (mm)
X Axis guideway type : 2 (pcs) * Linear Roller Guide (45mm)
Y Axis guideway type : 2 (pcs) * Linear Roller Guide (55mm)
Z Axis guideway type : 2 (pcs) * Linear Roller Guide (45mm)
Rapid feed X*Y*Z : 15*15*15 (m/min)
Cutting feed X*Y*Z : 10 (m/min)
Machine dimensions (WxDxH): 5.300 * 3.500 * 3.800 (mm)
Approximate Machine Weight: 19.000 (kg) (Varies according to options)
