Standard Machine Features
Fanuc 0i-TF Plus Control Unit
Strong and Wide Body Structure
Box way on All Axes
1.000mm Chuck diameter
200x200mm Sliding pillow section
Pallet Type Chip Conveyor
Central Lubrication System
Foot Pedal for Chuck Clamp-Unclamp
Fully enclosed case
3-color warning lamp
Interior lighting lamp
Machine mounting foot set
Tool Bag and Kits
CE Equipment
Transformer
User and Maintenance Manuals
Capacity Information
Max. swing over bed: Ø1.400 (mm)
Max. turning diameter: Ø1.250 (mm)
Max. turning height: 1.200 (mm)
Chuck diameter: Ø1.000 (mm)
Worktable load capacity: 4.000 (kg)
Max. spindle speed: 5 ~ 400 (rpm)
Spindle and motor transmission type: Gearbox (Double Speed)
Spindle motor power: 22 / 30 (kW)
Spindle motor torque: 210 (Nm)
Spindle torque (Output): 8.000 (Nm)
Square sliding pillow dimensions: 200 x 200 (mm)
Square tool dimensions: 40x40 (mm)
X axis travel: -50 ~ 650 (mm)
Z axis travel: 1.000 (mm)
Beam lifting stroke: 800 (mm)
Guide Type (X*Z): Box way
Ballscrew Diameter (X*Z): Ø63*63 (mm)
X*Z axis rapid feedrate: 12*12 (m/min.)
Cutting feedrate: 5 (m/min.)
X axis motor power / Torque: 3,5 (kW) / 22 (Nm)
Z axis motor power / Torque: 4,7 (kW) / 30 (Nm)
Machine dimensions (WxDxH): 3.500x2.600x3.700 (mm)
Approximate Machine weight: 12.500 (kg)
